Pre mixing the oil and others for countunies running,the movement of the planets in the barrel for material mixer planetary
motion,thus making the material feeding barrel fully mixing.
small capacity forming production line Plant milk cake rotary shaping machine baking oven
- $266,568.00
- $266,568.00
- Unit price
- per
Subtotal:
$266,568.00
10 customers are viewing this product
Couldn't load pickup availability
Free Shipping
Free standard shipping on orders over $69
Free Returns
Refund for No Delivery
Description
x
Product Description
|
Model
|
JY100
|
JY200
|
JY300
|
JY400
|
|
Production Capacity(kg/h)
|
100
|
200
|
300
|
400
|
|
Oven Length(m)
|
16
|
24
|
28
|
32
|
|
Gas Consumption(kg/h)
|
20
|
35
|
40
|
55
|
|
Electric Poewe(kw)
|
85
|
140
|
180
|
240
|
Cake mixer
Batter mixing
Aerating
Our aerating system use rotor and stator for more dense mixing needle structure, for the cake raw materilas,bigger chiller and dubble layer cooling system ensure the same cake pulp preparation temperature for the best emulsification.
Batter Depositing
Oil sprayer or paper place system
One by one sprayer on the cake molds for easy demolding after bake
If customer use cup holder paper we also have automatic cup place system
If customer use cup holder paper we also have automatic cup place system
Shape cake deposior
Servo depositing more easy to control and operate mechanical structure for easy maintance,the forming flow chat can be see on the touch scream
Layer cake depositor
Reciprocating feeding is to get even batter thickness across the band;1.5 to 2cm is to be left on both sided to avoid the batter spread to oven;
Cake(layer cake/swiss roll) weight control after oven by batter thickness adjustment.
Cake(layer cake/swiss roll) weight control after oven by batter thickness adjustment.
Hot air circulation oven- Convection (indirect) type
The working principle is indirect air impingement, an optimization of the well known convection principle. The heat from the gas burner is exchanged in the heat exchange above the baking chamber. The baking air is not mixed with the combustion air. Direct Impingement ovens are also available, where combustion air is circulated in the baking chamber.
The cake molds will autoamtic comeout form the oven and turn to one or two rolls to demolding.
Layer cake and swiss roll will directly bake on the belt.
The cake molds will autoamtic comeout form the oven and turn to one or two rolls to demolding.
Layer cake and swiss roll will directly bake on the belt.
Cake cooling & demolding
Cooling
Natural cooling and chiller cooling as operational.
Cooling tunnel design for two side of cooling can save 33% energy compair traditional screw type of chiller.
Cooling belt fixed inside the chiller so it wont casue the frosting on the belt or cake.
And less expose for better demolding and longer shelf life for the cake.
Cooling tunnel design for two side of cooling can save 33% energy compair traditional screw type of chiller.
Cooling belt fixed inside the chiller so it wont casue the frosting on the belt or cake.
And less expose for better demolding and longer shelf life for the cake.
Cake demolding system
There are two ways of demolding:Vacuum type and pin type.
Both type the demolding head will move fornt&back up&down like a mechinal arm transfer to the cooling belt.
Both type the demolding head will move fornt&back up&down like a mechinal arm transfer to the cooling belt.
Cutting and rolling & filling and injection
After the cake roll cooling and creaming will go to cutting system,both side of the roll will be cutter first then roll and pack.
If for cup cake or shape cake then the injection filling system will inject the filling insde,to insure the better and more fiilings inside our injection system will has two-step filling.
Bottom&top or side injection system as choice.
Bottom&top or side injection system as choice.
Tray cleaning & Sterilization
The UV Sterilization line is the last process before the packing UV
Sterilization can make sure the cakes from non-hygiene
elements before packing.
For fully autoamtic process we also supplier autoamtic tray cleaning and drying system.
